Components

data, relationships, and meaning – packed neatly in boxes

The Building Blocks of Your Entities

Components are data attached to Entities! They're how you give entities properties, behaviors, and relationships. From simple values to complex relations – components make your game world come alive.

What is a Component?

A Component is any piece of data attached to an Entity. In fennecs, components can be value types, reference types, tags, or even relationships to other entities and objects!

// Simple data component
entity.Add(new Position { X = 10, Y = 20 });

// Tag component (zero-size marker)
entity.Add<Enemy>();

// Relation to another entity
entity.Add<ChildOf>(parentEntity);

// Link to a managed object
entity.Add(Link.With(gameObject));

Whenever a Component is added or removed, the Entity moves to a new Archetype.

Quick Reference

Component Type	Description	Documentation
Value Types	Structs stored contiguously – fast & cache-friendly	Values
Tags	Zero-size markers for categorization	Tags
Shareables	Reference types shared between entities	Shareables
Relations	Entity-to-entity relationships	Relations
Object Links	Links to managed objects	Links
Expressions	Meta-level component references	Expressions

Component Rules

Entities can have:

1. Zero or one of each Component Type Expression (Type + Relation Target)
2. Any number of components (as long as their Type Expressions are unique)

Type Expressions

A TypeExpression combines a component's backing type with an optional relation target. This means you can have multiple components of the same type if they have different targets!

Examples

Plain Component

// Plain Data Components - The most common case
record struct Cash(decimal Amount);
record struct Height(float Meters);

bob.Add<Cash>(new(3.25M)); // bob has $3 and 25 cents
bob.Add(new Height(1.85f)); // bob is 1.85 meters tall

Entity-Entity Relation

// Components can carry a Relation to another Entity
record struct Owes(decimal Amount);

bob.Add<Owes>(new(10M), alice); // he owes alice $10
bob.Add<Owes>(new(23M), eve);   // and owes eve $23

// Each relation is a separate component!
bob.Ref<Owes>(eve).Amount += 7M; // modify eve's balance

Shared Component

// Reference types can be shared between Entities
Bank chase = new("Chase"); // Bank is a class!

// Many entities can reference the same instance
eve.Add<Bank>(chase);
bob.Add<Bank>(chase);
// Both now share the same Bank object

Object Link

// Components can BE an object (the link IS the data)
bob.Add(Link.With(chase)); // bob banks at chase
bob.Add(Link.With(targo)); // bob also banks at targo
// Two Bank relations, each backed by the object itself

What Components Can Do

Capability	Description
Add/Remove	Attach or detach from entities (single or bulk)
Any Type	Backed by any C# language type
Relations	Have an optional Target as secondary key
Sharing	Reference types can be shared between entities
Queries	Queried and processed by Streams

Archetypes

fennecs is an Archetype-Based ECS

Archetypes are internal collections of Entities that share the same set of Components. As an ECS user, you never interact with Archetypes directly, but understanding them helps you get the most out of fennecs.

By grouping Entities into Archetypes, the ECS (and by extension the CPU) can process them very efficiently.

fennecs constantly ensures that Entities with the same Components are stored tightly packed together in memory, which is a key factor in achieving high performance.

Performance Tip

In large projects, aim for either:

• Few, small archetypes (dozens of entities)
• Large, chunky archetypes (10k+ entities)

This maximizes cache efficiency during iteration.

Archetype Internals

There's no practical limit to Archetypes and their sizes. Archetypes can get compacted or removed by the World's garbage collector.

This is especially true for Archetypes of Relation Targets when the target despawns – because that Archetype is extremely unlikely to ever get any Entities again.
